Battery Management System 8-16S LiFePO4 LiPo
Battery Management System 8-16S LiFePO4 LiPo
Pre-Order February 2026 - Enquire Now
Supports 8–16S configurations with robust, isolated CAN for data and control. Features ultra-low quiescent current (~200μA) for efficient power usage. Built-in protection circuitry safely disconnects charge or discharge paths under fault conditions, ensuring reliable and safe operation for demanding robotics and embedded applications.
Features
8-16S Battery Configuration
45A Maximum Continuous Current
Data & control over isolated CAN interface
Low quiescent power draw (~200μA)
Protection circuitry disconnects charge or discharge under fault conditions.
Accurate Current Sensing
Advanced State of Charge Estimation
High-Side MOSFET Switching to Connect and Disconnect Battery
Protections
Cell Undervoltage to prevent underdischarge (CUV)
Cell Overvoltage to prevent overcharge (COV)
Overcurrent (OCP)
Short-Circuit (SCP)
Permanent fuse can be programmed to permanently disable battery after severe faults.
